Medium Frequncy Inverter DC Rolling Seam Welding Machine
The machine features
1. Include two standard models: horizontal seam roller welding machine and longitudinal seam roller welding machine;
2. The machine can also have a combination of horizontal seam welding and longitudinal seam welding two functions, as long as it will change my wheel in the direction of the electrode and replace a second electrode on the arm, can easily switch to do the two types of welding;
3. The single-wheel adopts three-phase no-pole speed adjusting drive, and the welding speed is easy to adjust to ensure that the tangent speed of the two rounds is consistent;
4. Adopt adjustable air cylinder pressure to avoid collision damage of upper and lower electrodes;
5. It is widely used in metal manufacturing and processing industries, such as hardware, home appliances, automobile, motorcycle oil tank, basin, water tank and canning.
Main Technical Parameters： Model MF-10KA MF-18KA MF-25KA MF-32KA MF-40KA MF-60KA MF-80KA Rated Voltage 3phases，（AC）, 380or 415or 480V,50/60HZ. Rated Capacity 30KVA 50KVA 90KVA 150KVA 170KVA 250KVA 300KVA Rated Duty Cycle 50% 50% 50% 50% 50% 50% 50% Max Welding Current 10000A 18000A 25000A 32000A 40000A 60000A 80000A Electrode Stroke 60MM Welding Arm Spacing 380MM Air Source Pressure 0.6MPa Cooling Water Flow 5L/minute 16L/Minute 25L/Minute 35 L/Minute 45L/Minute
