Battery SpotWelder
Main Features：
1.There aretwo Model:AMP-10K AC Battery Spot Welder and DPM-10K DC Battery Spot Welder;
2.Adopt theprinciple of Single sided, two points, and over-current welding,doesn’t damagethe internal structure of welded workpieces;
3.Beautiful welding traces, small spark, noblack (The battery won’t sag or fluid flow after spot-welding). It completelyovercomes the problems that the lithium battery has low pressure and the fluidflows out of the battery. This spot welder is the most ideal assembly equipmentfor battery production;
4.Thepressure of welding pins and the distance between the two pins can be regulatedindependently. And the regulation is quite convenient to make sure that thewelding pressure is stable and reliable;
5.Beautiful, light and handy in design;
6.DPM-10K advantage:controller LCD paneldisplays welding parameters making process control more accurate and moreconvenient,Input DC,welding area more beautiful.
MainApplications
Battery Pack Production, Custom BatteryPacks, Battery Pack Re-building, Battery Cell Tabbing Weld Alkaline, Ni-cd,Ni-MH, Li-Ion Cell Types, etc.
Main Technical Parameters：
SPECICATIONS | APM-10K | DPM-10K |
Output Power | 10KVA | 10KVA (LCD Display) |
Drive Style | Pedal/Pneumatic | Pedal/Pneumatic |
Output Signal | Opto-electric Switch | Opto-electric Switch |
Welding Current | AC 0-99%(Adjust) | DC 0-99% (Adjust) |
Electrode Diameter | Φ3 | Φ3 |
Input Power | AC 110-220V±10%/50Hz-60Hz | AC 220V±10%/50Hz-60Hz |
Welding Power | AC Pulse | Inverter DC |
Electrode Stroke | 15mm | 15mm |
|
