Structure | All-in-one?structure, door with?explosion-proof?lock?and?explosion-proof chain |
Temperature Range | Room temperature |
Display?Mode | PLC touch screen display (7-inch touch screen) + remote control |
Unit | Kpa |
Internal Chamber Dimension | W600xD600xH600 mm |
External Chamber Dimension | W940xD780xH1620 mm |
Internal?Chamber?Material | Reinforced steel + stainless steel (thickness?6.0mm) |
External?Chamber?Material | SECC steel plate,?Fine powder paint?coating?(thickness 1.5mm) |
Timing?Range | 99H 59M 59S |
Observation Window | 390 X 360mm(20mm thick tempered glass with explosion-proof film) |
Air?Pressure | Normal pressure ~5Kpa (Adjustable) |
Controlling?Mode | PLC touch screen display + remote control |
Power?Supply | AC 220V?/?50HZ?/ 1KW |
USB?Interface | With USB interface,?the?test data?can be?output |
Options | Video surveillance system, terminal device |
